Biomass Poplar wood pellet machinery

  • Biomass Poplar wood pellet machinery
  • Biomass Poplar wood pellet machinery
  • Biomass Poplar wood pellet machinery
  • Biomass Poplar wood pellet machinery

Biomass Poplar wood pellet machinery

    Payment Type: L/C,T/T,D/P,Paypal,Money Gram,Western Union
    Terms of Trade: FOB,CFR,CIF,EXW,FCA,CPT,CIP
    Min. Order: 1 Set/Sets
    Delivery Time: 7-10 Days
    Packaging: Favourable Export Package
    Productivity: 2.0-3.0t/h 1t/h, 3-4t/h
    Brand: Kingoro
    Transportation: Ocean,Land,Air,through transport
    Place of Origin: China
    Supply Ability: 100sets/mon
    Certificate: ISO, CE, SGS
    HS Code: 84793000
    Port: Qingdao Port,Other Required

Basic Info

Model No.: SZLH700

Product Description

How is wood pellet produced by wood pellet mill

Wood Pellets are produced by compressing the wood material which has first passed through a hammer mill to provide a uniform sawdust-like mass. This mass is fed to a wood pellet mill where it is squeezed through a die having holes of the size required (normally 6 mm diameter, sometimes 8 mm or larger). The high pressure of the wood pellet machine causes the temperature of the wood to increase greatly, and the lignin plasticizes slightly forming a natural ‘glue’ that holds the wood fiber together to form wood pellet as it cools.

wood pellet mill


Specification of Kingoro Pellet Machine Biomass Wood Pellet Mill

Model Power kw Capacity t/h Size mm Weight ton
SZLH580 90 1.2-1.5 2400x1300x2100 5.5
SZLH600 110 1.3-1.8 2400x1300x2100 8.6
SZLH660 132 1.5-2 2500x1300x1900 8.8
SZLH700 160 1.8-2.5 2550x1600x2000 7.6
SZLH860 220 2.5-3.5 2800x2000x2300 13

Advantages of Our Vertical Ring Die biomass Wood Pellet Mill
1. Big Gear Transmission
The gear of reducer is bigger(right picture), and the teeth joint surface becomes bigger, so its load bearing capacity is strenthened, which extends its service life longer 3-5 times

than usual reducer(left reducer)
pellet machine reducer

2. Feeding Vertically
Raw material is feeding vertically and is directly in place, with stationary die and rotary pinch roller, the material is centrifugal and spread evenly around the die.
pellet mill ring die

3.Doule Layer Ring Die
Each layer has 4-6 row of holes. The more holes, the much larger capacity.

The most important, Double layer extends ring die's service life. When one side is damaged or wornout, the other side is avaliable to be turned upside down to go on work.
ring die
4. Independent outlet device
The independent ejection device ensures the forming rate of pellet, the good design lowers the consumption and enhances the efficiency. It works 24 hours and lubricates automatically.
5. High Alloy Forged parts
The main load-carrying component used high alloy wear resistant materials. the wearing parts lifetime doubles compared with other similar products.

Stainless ring die and alloy steel ring die of kingoro wood pellet mill

 ring die pellet machine

Roller Skin of Kingoro Wood pellet mill

roller skin


A set of wood pellet mill including feed screw conveyor, wood pellet mill, grease pump, duxt removal and connecting tubes

pellet mill machine



Requirements for biomass vertical Ring Die Biomass Wood Pellet Mill Machine

Size: All the raw materials must be crushed into sawdust (less than 7mm)before going into pellet mill

Moisture: Generally, 10-15% is best for quality biomass pellets.


All precesses of biomass pellet production line for making pellets

123

Pictures of biomass vertical ring die biomass wood pellet mill machine


photobank (11)
pellet mills

wood pellet machine surporting facilities


Client Cases of Kingoro Pellet production line

photobank (6)

About our Factory

Shandong Kingoro Machinery Co.,Ltd, established in 1995, is specialized in manufacturing biomass fuel pellet making equipments, animal feed pellet making equipments and fertilizer pellet making equipments, including complete sets of a production line: crusher, mixer, dryer, shaper, siever, cooler, and packing machine.
According to specific requirements of our customers, we are enjoy to offer risk evaluation and turnkey solution plans.

We focus on inventation and innovation. 17 patents are our achievement in scientfic research.
Our products are certificated with ISO9001, CE, SGS Test Report.
Our Main Products
A. Biomass Pellet Mill
1.Vertical ring die pellet machine 2.Flat pellet machine
B. Feed Pellet Mill
C. Fertilizer Pellet Machine

D. Complete Pellet Production Line, including debarker, chipper, hammer mill, Screener, drum dryer, pellet machine, cooler, pacakging machine, etc


photobank (7)

photobank (95)

Certificates for pellet machine

ISO-2

CE

When enquiry, if let us know the following information, you will get our quick response and better quotation.
1. What's the capacity you plan to produce?
2. What's the raw material?
3. What's the your raw material?
4. What's the moisture content of your raw materials?
5. What's your country voltage?

If Any Question, Please Leave Me Message Below.
